Information Delivery Specification (IDS)

Define your exchange requirements with IDS to build confidence, clarity and enhance interoperability

What is IDS?

Information Delivery Specification (IDS) is a buildingSMART standard for defining information requirements in a computer interpretable form. It allows for automatic compliance checking of IFC models, that increases quality control and fidelity of data. IDS also aids the efficient delivery of the data, by setting the expectations and providing clear guidelines of what needs to be exchanged. A user of IDS can specify how objects, classifications, materials, properties, and even values should be delivered in an IFC model.

Read the documentation

Previous versions
All the versions of IDS prior to 1.0 are not an official standard.

IDS 1.0
On 1st June 2024 the IDS has been approved and became the official buildingSMART standard!

Future versions
We are collecting feedback on the improvements needed for the IDS 1.1 and 2.0 versions.

IDS example

Human-friendly 👓

All walls should have the property FireRating in the set Pset_WallCommon with a value being one of REI30, REI60, REI90.

Computer interpretable 💻

<ids:ids xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://standards.buildingsmart.org/IDS http://standards.buildingsmart.org/IDS/1.0/ids.xsd" xmlns:ids="http://standards.buildingsmart.org/IDS">
<ids:info>
<ids:title>Example IDS</ids:title>
<ids:version>1.0</ids:version>
<ids:author>[email protected]</ids:author>
<ids:date>2024-01-06</ids:date>
</ids:info>
<ids:specifications>
<ids:specification ifcVersion="IFC4X3" name="Walls need fire rating" identifier="S1">
<ids:applicability minOccurs="0" maxOccurs="unbounded">
<ids:entity>
<ids:name>
<ids:simpleValue>IFCWALL</ids:simpleValue>
</ids:name>
</ids:entity>
</ids:applicability>
<ids:requirements>
<ids:property dataType="IFCLABEL" uri="https://identifier.buildingsmart.org/uri/buildingsmart/ifc/4.3/prop/FireRating" cardinality="required">
<ids:propertySet>
<ids:simpleValue>Pset_WallCommon</ids:simpleValue>
</ids:propertySet>
<ids:baseName>
<ids:simpleValue>FireRating</ids:simpleValue>
</ids:baseName>
<ids:value>
<xs:restriction base="xs:string">
<xs:enumeration value="REI30" />
<xs:enumeration value="REI60" />
<xs:enumeration value="REI90" />
</xs:restriction>
</ids:value>
</ids:property>
</ids:requirements>
</ids:specification>
</ids:specifications>
</ids:ids>

Automated validation ✅

🗹 7/10 walls passed the requirement.
🗷 2/10 walls don’t have a FireRating property.
🗷 1/10 wall has a FireRating, but the value is “REI_60” which is not allowed.

IDS in Practice

In this video, learn about the fundamentals of IDS and how it was developed. See what software tools are available and ready for use and see how it plays an important role in the overall openBIM workflow.

Learn more about the openBIM workflow

Why use IDS?

Clarity

IDS helps you automate data exchanges thanks to its clear and strict structure and well-defined requirements.

Confidence

Enhance interoperability by controlling the quality and reliability of data with IDS.

Consistency

Ensure all project data adheres to the same specification through the IDS standard.

"By adhering to openBIM standards, like IDS, we can show that standardization enhances project efficiency and quality. This helps improve automation that streamlines compliance checking and validation processes, saving time and boosting productivity."

York Tang

R&D Manager at Wings & Associates Consulting Engineers Limited

IDS news

IDS in Practice

3rd July 2024

Information Delivery Specification (IDS) v1.0 is Approved as a Final Standard

4th June 2024

The Information Delivery Specification (IDS) Final Standard is now out for review by the Standards Committee.

6th March 2024

Use IDS with popular software

30+ more

The list above is randomized and buildingSMART does not favor any particular solution.

Frequently Asked Questions

How does IDS differ from other information requirement standards?

IDS, unlike most other information requirement standards, is strictly tied to the IFC data schema. It enables unambiguous interpretation and automatic compliance checking, providing identical results in all checking software. IDS is limited to alphanumeric information, meaning values of properties, quantities, classifications, materials and relations, but doesn't cover geometrical aspects. IDS format can be used in combination with other standards, for example, to capture Exchange Information Requirements (ISO 19650), Level of Information Needs (EN 17412), or Product Data Templates (ISO23387).
Read more about the comparison in the blog post: "Methods to specify information requirements in digital construction projects"

What is the link between IDS and bSDD?

Both IDS and bSDD are there to capture agreements on data content. While IDS is a standard, formalizing how to capture them, the bSDD is a service containing many terms and definitions that can be used in the agreements. Think of bSDD as a shared library of properties that can be utilized when preparing an IDS. Thanks to this synergy, we popularize the usage of consistent terms across the industry. Read more about the bSDD here: https://bsdd.buildingsmart.org/.

What is the difference between IDS versions?

IDS v1.0 is now approved as a final standard. All the previous versions, such as 0.4.2 and 0.9.6, were beta iterations and never an official standard. They differed in details of XML structure and attributes, and the differences can be traced in the IDS repository change history: https://github.com/buildingSMART/IDS. Modern tools support upgrading older version IDS files to the 1.0.
There is a plan to release minor fixes and software implementers agreements in version 1.1, and a long-term plan of releasing an IDS 2.0 containing improvements.

What's the difference between IDS checking and IDS audit?

What should come first, IDS specification or IFC data?

Is IDS a file format?

IDS technical documentation

The IDS standard is captured in an XML Schema (XSD). Apart from that, buildingSMART provides a thorough documentation including implementers agreements and guidelines. The official GitHub repository is where collaborators can propose and discuss updates and implementation challenges. To ensure complete implementation, we provide a comprehensive test suite for auditing all the IDS aspects.
